Name: Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000
Brand: Beijing Ding Ding Future Technology Co.Ltd
SKU: Serra 25 - 110/230-277
Price: 1 USD
Availability: InStock

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

MOQ

1 USD

preço

Características Galeria Descrição de produto Peça umas citações

Características

Especificações

Marca: CE+T

Número do modelo: Serra 25 - 110/230-277

Nome do produto: Conversores /UPS

Número da peça: T721D50201

Tensão de saída CA: 110VDC

Dados de entrada CA: 230 Vac / 11,8 A, 240 Vac / 11,0 A e 277 Vac / 9,5 A

Dados de entrada de CC: 110 Vdc (90 - 150 Vdc)

Eficiência: DC/AC: > 93,7%

Eficiência: AC/AC: > 96% / > 93,7% / > 93,7%

GW: 6KG

Informação básica

Lugar de origem: CN

Marca: CET

Certificação: CE UL

Número do modelo: Serra 25 - 110/230-277

Condições de Pagamento e Envio

Detalhes da embalagem: caixas de madeira

Tempo de entrega: 6-8 semanas

Habilidade da fonte: 500 conjuntos/mês

Galeria

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

Descrição de produto

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 0

CE+T Sierra 25 Bidirectional Industrial Power Converter 2.7kW–2MW Sierra 25 - 110/230-277 T724D50010

Description:

Sierra 25 – 48/230-277 can be used as a UPS to secure AC & DC loads and charge the batteries.

The 3 all bidirectional ports allow for multiple innovative applications such as grid reinjection, peak shavings,

phase balancing or energy sharing through DC distribution, among many others.

By using several modules, we can offer solutions for three-phase (3x400Vac + N) infrastructures.

The module can be integrated in small or large cabinets to reach up to 2 MW.

With our new Inview S monitoring, you can benefit from a unique experience.

The total output power per module is 2.7 kW, limited to 2.4 kW for each AC or DC port.

Key Features:

Secure AC & DC loads;
Many innovative applications;
Compatible with Inview S;
Modularity: from 2.7 kW to 2 MW;
From small to large systems.

Versions:

4 modules can be integrated into 2U high shelves to provide up to 10.8 kW (AC + DC)

Parameters:

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 2

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 3

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 4

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 10

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 11

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 14

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 15

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 16

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 17
